1-8
X9DRD-iF/LF Motherboard User’s Manual
I/O De-
vices
Serial_Link Connections
• SATA Ports Two (2) SATA 3.0 Ports (I-SATA0/1)
Four (4) SATA 2.0 Ports (I-SATA2~5)
(X9DRD-iF)
(I-SATA 0/1 only: X9DRD-LF)
Four SCU Connections (SCU0~3)
(X9DRD-iF)
• RAID (Win-
dows & Lat-
est Linux)
RAID 0, 1, 5, 10
(RAID 5, 10: X9DRD-iF)
Integrated IPMI 2.0
• IPMI 2.0 supported by the WPCM450R BMC
Serial (COM) Port
• Two (2) Fast UART 16550 Connection: 9-pin RS-232
port
(COM1: X9DRD-LF)
Super I/O
• Nuvoton 83527HG
Peripheral
Devices
USB Devices
• Four (4) USB ports on the rear I/O panel (USB 0/1,
USB 2/3)
(Backpanel USB 0/1: X9DRD-LF)
• Four (4) USB connections for front access (USB 4/5,
USB 8/9)
(Front access USB 4/5: X9DRD-LF)
• One (1) Type A USB connection for front access (USB 6)
(X9DRD-iF)
BIOS
• 16 MB SPI AMI BIOS
®
SM Flash BIOS
• APM 1.2, PCI 2.3, ACPI 1.0/2.0/3.0/4.0, USB Keyboard,
Plug & Play (PnP) and SMBIOS 2.3
Power
• ACPI/APM Power Management
Cong.
• Main switch override mechanism
• Keyboard Wake-up from Soft-Off
