D-9
Appendix D: SAS-846A Backplane Specications
Rear LED Indicators
Rear LED Hard Drive Activity Failure LED
SAS #0 D12 D5
SAS #1 D13 D6
SAS #2 D14 D7
SAS #3 D15 D8
SAS #4 D18 D19
SAS #5 D21 D20
SAS #6 D22 D23
SAS #7 D24 D29
SAS #8 D25 D30
SAS #9 D26 D31
SAS #10 D27 D32
SAS #11 D28 D33
SAS #12 D40 D37
SAS #13 D41 D38
SAS #14 D42 D39
SAS #15 D87 D88
SAS #16 D100 D103
SAS #17 D101 D105
SAS #18 D102 D107
SAS #19 D104 D108
SAS #20 D106 D109
SAS #21 D111 D110
SAS #22 D118 D119
SAS #23 D120 D121
