Superwinch H11P - Description

1 M8x150 Hex Head Bolt 4-33-0815022 6
2 M8 Lock Washer 4-51-0823 16
3 Gearbox Cover 53-25054 1
4 1st Stage Thrust Pad 53-52224 1
5 1st Stage Ring Gear 88-32288-01 1
6 1st Stage Carrier Assembly 53-90270 1
7 2nd Stage, Sun Gear 53-54033 1
8 Ring Gear Spacer 53-50421 1
9 Sun Gear 1st Stage 53-54036 1
10 Drive Shaft Coupling 53-70032 1
10a Coupling Spacer 53-52270 1
11 Drive Shaft — 10” Drum Models: 53-50466 1
5364, 5365, 5370, 5371, 5374, & 5375
Drive Shaft — 11.4” Drum Models: 53-50467 1
5366, 5367, 5372, 5373, 5376, & 5377
12 6mm x 6mm Key 4-178-060645 1
13 Thrust Washer, 2nd Stage 53-52241 1
14 2nd Stage Carrier Assembly 53-90271 1
15 Thrust Washer, 2nd Carrier 53-52223 1
16 Wave Spring 4-156-211195130 1
17 2nd Stage Ring Gear 53-54037 1
18 Spring Pin 4-56-804003 3
19 Oil Seal, Carrier Body 4-22-7078053 1
20 Ring Gear Spacer 53-50374 1
21 Sliding Dog 53-25055 1
22 Spring Pin 4-56-602603 1
23 Clutch Fork 53-52295 1
24 Gear Box Housing Assembly 53-90273 1
25 Freespool Pivot Shaft 53-50456 1
26 Drag Button Spring 320 2
27 Drag Button 317 2
28 Latch Plate 53-60173 1
30 M8x20 Hex Head Bolt 90-23239-08 1
31 M8x16 Hex Head Bolt 4-32-0801622 1
32 M8 Flat Washer 4-50-0823 1
33 Handle Assembly 53-90396 1
34 ‘V’ Face Seal 4-22-130151123 2
35 Drum Bearing 53-40953 2
36 10” Long Drum Assembly 53-90150 1
Models: 5364, 5365, 5370, 5371, 5374, & 5375
11.4” Long Drum Assembly 53-90151 1
Models: 5366, 5367, 5372, 5373, 5376, & 5377
Reference
Number Description Part Number Qty
H11/13/15P
PARTS LIST
22
Reference
Number Description Part Number Qty
23
37 Socket Head Set Screw M8 x 10 NA* 1
38 Tie Bar: 10” Long Drum Models: 53-52265 2
5364, 5365, 5370, 5371, 5374, & 5375
Tie Bar: 11.4” Long Drum Models: 53-52266 2
5366, 5367, 5372, 5373, 5376, & 5377
39 M12 x 1.75 -25mm long bolt 4-32-1202522 8
40 12mm Lock Washer 94-23057-07 8
41 Brake Housing 53-25057 1
42 Disc Spring 4-145-1125730 2
43 Pressure Plate 53-65026 1
44 Rotor (Hyd) Brake 53-90336 1
45 Thrust Washer, Rotor 53-52240 1
46 Stationary Disc 88-22313 3
47 Rotating Disc 53-60184 2
48 ‘U’ Seal, Brake Release (Sold only with 49) 1
49 Brake Repair Kit (includes Motor 53-95095 1
Mounting Hardware, 43, 46 & 48)
51 M8 x 40 Hex Head Cap Screw 4-33-0804022 8
52 5/16 - 18 x 2 1/2 Hex Head Cap Screw 88-23226-15 4
53 Lock Washer, 5/16 92-23057-03 4
54 Manifold 94-30054 1
57 Hydraulic Motor - H11P 94-32191-02 1
Models: 5364, 5365, 5366, & 5367
Hydraulic Motor - H13P 86-30077-01
Models: 5370, 5371, 5372, &5373
Hyraulic Motor - H15P 94-32192-04
Models: 5374, 5375, 5376, & 5377
58 Sliding Dog 53-25080 1
59 Gear Box Housing 53-25167 1
60 Thrust Washer 53-50438 2
61 ‘O’ Ring 4-21-1145 1
62 Freespool Piston 53-50437 1
63 ‘O’ Ring 4-21-1195 1
64 Retaining Ring 4-24-60718203 1
65 Spring 4-31-1068505803 1
NS Hydraulic Fitting 88-23299-01 3
NS Hose Assembly 86-22516 1
NS Bleed Nipple 4-92-193 1
* Purchase at hardware supplier
H11/13/15P
PARTS LIST
