CONTENTS
Description . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2
Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
Performance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
Mounting Specifications. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
Hydraulic Requirements/Components/Control Circuit . . . . . . . . . . . . . . . . . . . 7
Operation and Use . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
Installation and Care of the Wire Rope . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
Freespool . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
Fail Safe Brake . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
Safety Information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
Trouble Shooting and Maintenance Guide . . . . . . . . . . . . . . . . . . . . . . . . . . 14
Routine Maintenance. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
Lubrication . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
Hydraulic System Trouble Shooting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
Winch Trouble Shooting. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17
Parts List . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18
Superwinch Limited Warranty . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24
The H11/13/15P winches are hydraulic powered winches with an SAE-J-706
first layer rating of 11,000; 13, 000; and 15,000 lbs. Power from the hydraulic
system is supplied to the winch’s motor, driving a two stage planetary gear-
box. The output of the gearbox drives the rope drum, winding in the wire
rope in turn pulling or winching a load.
These winches are equipped with a hydraulic release, spring applied, multi-
ple disc, fail-safe dry brake. The brake is designed to lock and hold the load
whenever hydraulic pressure to the winch motor is interrupted.
These winches have a freespooling clutch which allows the wire rope to be
removed from the drum quickly. These winches are reversible so the rope can
be powered in and out using the directional control valve in the hydraulic circuit.
These winches are designed with many mounting options. They may be
mounted using the feet or rails, in a horizontal or vertical configuration.
The H11/13/15P winches are not intended or approved
for lifting, hoisting or the transportation of people.
DESCRIPTION
2
Drum Length Freespool
Model 10” 11.4” Man. Pneu. H11P H13P H15P
5364 X X X
5365 X X X
5366 X X X
5367 X X X
5370 X X X
5371 X X X
5372 X X X
5373 X X X
5374 X X X
5375 X X X
5376 X X X
5377 X X X
Max. Rated
Line Pull H11P H13P H15P
1st Layer 11,000 lbs. 13,000 lbs. 15,000 lbs.
(4990 kg) (5897 kg) (6804 kg)
Top Layer (See performance chart, page 4)
Drum Dia. 4 inches (101.6 mm)
Drum Length 10 inches (255 mm) 5364, 5365, 5370, 5371, 5374, 5375
11.4 inches (290 mm) 5366, 5367, 5372, 5373, 5376, 5377
H11P H13P H15P
Recommended
Rope Dia. and
Max. Rope Length 10” Drum 7/16 7/16 1/2
(214’/65.2m) (214’/65.2m) (153’/46.6m)
11.4” Drum 7/16 7/16 1/2
(257’/78.3m) (257’/78.3m) (184’/55.1m)
H11/13/15P
Weight
(Less Rope) 10” Drum 125 lb./56.7 k
Manual Freespool
10” Drum 127 lb./57.6 k
Pneumatic Freespool
11.4” Drum 127 lb./57.6 k
Manual Freespool
11.4” Drum 129 lb./58.5 k
Pneumatic Freespool
Operating Pressure
Continuous Min. 800 psi (55 bar)
Max. 2,000 psi (138 bar)
Intermittent Max. 2,250 psi (155 bar)*
Operating Flows
Continuous Min. 3 gal./min. (11.4 LPM)
Max. 15 gal./min. (57 LPM)
Intermittent Max. 20 gal./min. (76 LPM)**
Lubrication
Grease filled gearbox lubricated with Superwinch P/N 90-15020
* The intermittent pressure of 2,250 psi must not occur for a duration of more
than 2 seconds.
** The maximum intermittent pressure of 2,250 psi and maximum flow of 20 GPM
must not occur simultaneously. The winch motor will be damaged.
3
SPECIFICATIONS
