5.3.4 Power Supply Connector (POWER)
Operating Voltage: DC24V±20%.
The power switch of the weighing indicator should be turned off and ensure that the power cables are
not charged before DC24V power connection to avoid short circuit fault.
Find the DC24V terminal with relative stable voltage in the driving cab, then connect the terminal
‘+24V’of the weighing indicator to the FUSE, and connect ‘GND’ to the metal frame of the driving
cab.
Please make sure that the inputted voltage is correct before power-on.
No.
Pin
Wire Color
Description
4
GND
Black.
DC Input -.
5
+24V
Red.
DC Input +.
Note: Reverse polarity protection function available.
2
1
POWER
