Appendix B. Register Table of Host-Slave MODBUS[ASCII]
Data Name
Type
Address
Attribute
Command
[HEX]
Description
Totalized Loading Weight
Long
40001
R
03
Single-bucket-
loading-weight
Long
40003
R
03
Bucket Count
Long
40005
R
03
Present Record No.
Long
40007
R
03
Alarm State
Long
40009.0
R
03
1: Stall Alarm.
40009.1
40009.2
1: Undertime Alarm.
40009.3
1: Overtime Alarm.
40009.4
1: Upper Limit Alarm of
Single-bucket-loading-weight.
40009.5
1: Lower Limit Alarm of
Single-bucket-loading-weight.
40009.6
40009.7
40009.8
40009.9
40009.10
40009.11
40009.12
40009.13
40009.14
40009.15
……
40009.31
Real-time Weight Value
Long
40011
R
03
Display Unit of Loading
Weight
Short
40013
R
03
Display Unit of Totalized
Loading Weight
Short
40014
R
03
Ton-Decimal
Short
40015
R
03
Bucket State
Short
40016
R
03
0: ▲[Loading].
1: ▲[1].
2: ▲[2].
3: ▲[3].
4-7: ▼.
8: ■[Pause].
Setpoint
Long
40017
R
03
