40
 Correction Ratio [SP.R = New Span Coefficient / Old New Span Coefficient].
 AD: AD Value at Weighing Segment.
 ACC: Acceleration Value at Weighing Segment [dm/s
2
].
 R-AD: Real-time AD Value.
 Message ‘Save’: It’s allowed to save the detection results.
 Alarm Message: It’s not allowed to save the detection results.
 【Ent】: Save; 【Menu】: Exit without saving.
 Repeat the above steps for three times, if the variation of Span Coefficient is in the allowable
range, Span Calibration process will be completed.
 Press key【Pause】to enter Pause state with red sign ‘■’ displaying.
Alarm
Description
Sulution
【Too Small Signal】
AD Value < [Zero Value × 110%]
Check if there are enough materials loaded
in the wheel loader’s bucket.
Do ‘Oil Pressure Sensor Adjustment’ again.
【SPAN Limit】
Span Coefficient is not in the
allowed range [1~999999].
Do ‘Oil Pressure Sensor Adjustment’ again.
