Introduction
1-3
ABOUT YOUR NEW BOAT
Boat Terminology
You should understand, learn and use appropriate and common nautical
terminology while boating to ensure your safety and the safety of others. See
Glossary of Nautical Terms on page 14-1 for additional boating terminology.
Figure 2
Figure 1-2
Construction and Features
Construction begins outside-in, with our Integrated Composite System (ICS). ICS
is a 100% composite design that makes each Supreme Boat strong and uses a
three-piece construction process — hull, inner liner and deck. During construction,
gelcoat colors and full-contour graphics are sprayed into the molds, which ensure
that Supreme tow boats’ accents and graphics last all the way to the horizon.
After the gelcoat and fiberglass are applied and dried, giving the three ICS
components solid form, the deck, hull and liner are removed from their molds and
placed together. First, the inner liner is placed into the hull and bonded using a
material called Plexus
®
, which fuses fiberglass, creating an unbreakable seal. The
BOW
DRAFT
FREEBOARD
GUNWALE
STERN
WATERLINE
AFT
FORWARD
HELM
BEAM
TRANSOM
LENGTH OVERALL (LOA)
STARBOARD
SIDE
PORT
SIDE
KC-0069C-A
RUDDER
PROPELLER
STRUT
