General Care and Maintenance
11-5
ELECTRICAL SYSTEM
Before performing any work on the electrical system or battery, see Safety on
page 3-1 and 3-2.
Battery
Always turn off the battery switch (if equipped) or disconnect the negative battery
cable before servicing the electrical system.
When you install a battery:
• Always use correct polarity when you connect the battery cables to the battery.
• Make sure the battery terminals are clean.
• Make sure the cable connections are tight.
• Always shut down the engine before removing or attaching battery cables and
never run the engine with the battery cables disconnected.
• Always remove the negative (-) cable first. Always attach the negative (-) cable
last.
Figure 11-2
Check the battery frequently for signs of corrosion. If corrosion is evident, clean
the terminal posts with a baking soda and water solution and a wire brush.
Disconnect the battery terminals before cleaning.
Check the fluid levels in the cells. NOTICE: Some batteries are sealed and cannot
be filled. A level of approximately 1/4 to 1/2 in. (6 to 13 mm) above the plates is
sufficient. If needed, fill with distilled water; do not overfill. WARNING! Lead-acid
battery fluid can cause severe burns.
KC-0151C-A
VENT CAP
MAXIMUM
LIQUID
LEVEL
MINIMUM
LIQUID
LEVEL
PLATES
TERMINAL
POST
VENT WELL
Supreme_2018.book Page 5 Wednesday, January 31, 2018 9:30 AM
