the greater field of view makes objects seem further away than they really are. Care must be
used when judging the distance of objects seen in these mirrors.
B. Rear Brake Lever
For description and operation, see “Feature Introduction”, on page 6.1.
C. Parking Brake Lever
For description and operation, see “Feature Introduction”, on page 6.2.
D. Rear Brake Fluid Reservoir
For description and operation, see “Maintenance”, on page 10.5.
E. Left Handlebar Control
For description and operation, see “Feature Introduction”, on page 6.1.
F. Dashboard
For description and operation, see “Display and Indicator”, on page 4.1. and “Feature
Setting”, on page 5.1.
G. Key Switch/Steering Lock
For description and operation, see “Starting and Operating”, on page 7.2.
H. Front Brake Fluid Reservoir
For description and operation, see “Maintenance”, on page 10.6.
I. Motor Stop Switch
For description and operation, see “Feature Introduction”, on page 6.3.
J. Front Brake Lever
For description and operation, see “Feature Introduction”, on page 6.3.
K. Right Handlebar Control
For description and operation, see “Feature Introduction”, on page 6.3.
L. Throttle grip
For description and operation, see “Feature Introduction”, on page 6.3.
M.USB port
5V 2.4A USB port。
N. Seat Installation bolt
Fix the seat on the frame，see “Feature Introduction”, on page 6.3.
3.4
