Caution: The appearance of front fork in different brands may be different, please refer to the
actual product.
Caution: The damping and spring preload should be adjusted reasonably according to the road
conditions and the weight of the rider. Avoid adjusting the damping to the maximum limit
value, otherwise the front fork may malfunction or even cause a crash.
4.10
Rear shock adjustment
Compression adjustment——FASTACE、KKE
The compression adjustment screw is located on the top right side of the rear shock absorber.
"+" is printed on the adjusting screw to indicate hard (large compression damping) and "-"
indicates soft (small compression damping).
• Turn the adjusting screw ○A clockwise in the "+" direction to increase the compression
damping.
•Turn the adjusting screw ○A counterclockwise in the "-" direction to reduce the compression
damping.
