Sure Electronics A2100 - Page 3

Component and Funcon
2
1
2 3
4
1—3.5mm audio input
2—3.5mm headphone output
3—Volume knob
4—IR remote receiver
+
- -
+
7
8
+
- -
+
1
2
3
4
5
6
7
8
1—Speaker output 2—Power input
3—USB sound card*
4—Subwoofer output
5—Subwoofer volume control* 6—Audio signal input (RCA)
7—Opcal fiber input 8—Bluetooth receiver
* Available for next version
+
- -
+
Power
Connecon
3
FIGURE 3-1 Front panel
FIGURE 3-2 Rear panel
To subwoofer amplifier From MP3,
CD player,etc.
From set top box,
desktop,etc.
Adjust the bass
level by pot
Available for
next version
Available for
next version
