Sure Electronics A2100 - 10 Mechanical Drawing

Specificaon9
Contact Us
11
Mechanical Drawing10
FIGURE 6-1 Front panel
FIGURE 6-2 Rear panel
124/
[
4.88
]
120/
[
4.72
]
FIGURE 6-3 Side view
217/
[
85.43
]
4/ 0.16
mm [inch]
mm [inch]
mm [inch]
Parameters Condions Min Typ Max
Power Supply Range(VDC) 12 24 32
Idle Power(W) 0.4 0.5
Standby Power(mW) Only When Low Power Module Available 2 10
Input Sensitvity(mV)
RCA,24V @ 4Ω, 100W 700 775 850
3.5mm 700 775 850
Bluetooth 700 775 850
USB Sound Card 700 775 850
Toslink/ Coaxial 700 775 850
Supports Sampling Rate(KHz) 48
Digital Audio Input Coaxial or Toslink
Input Impedance(KΩ) RCA / 3.5mm 15 20 25
Gain(dB) 23 26 29
Output Power for Speaker(W) 24V @ 4Ω,THD+N=10% Single Channel 100
Efficiency
100W,24V @ 4Ω Single Channel
85%
88%
90%
24V, No Audio Input
/
/
/
,24V @ 4Ω, 100W
/
,24V @ 4Ω, 100W
,24V @ 4Ω, 100W
,24V @ 4Ω, 100W
Open space, no phsical obstrucons
/
BT Wireless Range(M)
/
/
/
10
/ /
Main Product
Combinaon Product
SKU Price Item Listed Price
AA-AS32189 2 X 100W A2100 Class D Audio Amplifier Explorer $69.90
PS-SP11575
Mean Well GS120A24-R7B Desktop Adapter Power
Supply 24V
5A 120W
$49.90
MB-CM11111 Small 7-key
Remote
Control
$5.99
SKU Price Item Listed Price
AA-AC11158
2 X 100W A2100 Class D Audio Amplifier Explorer
with Bluetooth, Remote Control & Adapter
$119
