Power Supply
1
Suggested power supply should be 350W, DC36V. You can also use
any power supply whose output voltage is within DC10-39V and
current is higher than 4A. Please note power supply out of the
recommended range may cause damage to the amplifier board.
We recommend 350W Single Output Switching Power Supply LRS-
350 Series. We also recommend Mean Well GST-160A 36V version.
The terminal interface used for power supply is Molex MiniFit-
2x2Pos-4.2mm.
A power supply cable is in basic cable, which comes as a standard
accessory with JAB5 in the package. You can connect the cable to
Mean Well GST-160A.
1. Power supply – J15
J15
