• An antenna (CM100-L,
• A Yagi antenna (such as the CM230W) must be
mounted horizontally and be aimed at the
desired cellular tower (line of sight).
CAUTION: MOUNT THE EXTERIOR
ANTENNA ON A FIXED STRUCTURE .
WARNING: FAILURE TO EXERCISE CAU-
TION WHEN WORKING IN HIGH AREAS
COULD CAUSE A FALL AND PERSONAL
INJURY.
WARNING: DO NOT TOUCH ANY LIVE
ELECTRICAL WIRES OR ALLOW THE
ANTENNA OR CABLING TO TOUCH ANY
LIVE ELECTRICAL WIRES.
1. Mount the antenna.
2. Connect a length of CM400 cable to the
3. Run the cable along the planned route.
4. Install a properly grounded CMLP lightning
protector.
5. Seal any holes you make in the outside of the
building with appropriate caulking or sealant.
4.4 - Internal Antennas
Mount the interior antenna(s) in the
you selected during the planning process. Be sure
CAUTION: AVOID AIMING A YAGI
ANTENNA TOWARD ANY INTERIOR
ANTENNA .
(Please not, the CM100-L and CM100-S antennas are dual band
and the CM288W and 230W antennas are wide-band.)
