11
Kitting Information
Fusion2Go 2.0 US
PreAGC
Pulse GSM
Frequency Input Output Gain
(MHz) (dBm) (dBm) (dB)
Uplink: 1710-1755 -18.2 26.3 44.5
Uplink: 1850-1915 -19.9 23.4 43.3
Uplink: 824-849 -18.5 27.1 45.6
Uplink: 698-716 -21.3 26.3 47.6
Uplink: 777-787 -21.1 26.0 47.1
Downlink: 2110-2155 -43.8 0.5 44.3
Downlink: 1930-1995 -45.7 -0.1 45.6
Downlink: 869-894 -44.7 2.0 46.7
Downlink: 728-746 -46.3 -0.3 46.0
Downlink: 746-757 -44.0 0.7 44.7
Fusion2Go 2.0 Canada
CW (Sinusoid Signals)
Frequency (MHz) Bandwidth (MHz) Input (dBm) Mean Power (dBm) Gain (dB)
Uplink: 1710-1755 82.0 -22.0* 24.1 46.1
Uplink: 1850-1915 73.7 -26.4* 19.8 46.2
Uplink: 824-849 36.8 -23.3* 24.2 47.5
Uplink: 698-716 25.0 -22.8* 25.0 47.8
Uplink: 777-787 22.7 -24.0* 23.0 47.0
Downlink: 2110-2155 81.8 -31.5* 13.3 44.8
Downlink: 1930-1995 76.5 -26.3* 17.5 43.8
Downlink: 869-894 39.2 -31.6* 14.1 45.7
Downlink: 728-746 36.0 -28.4* 18.3 46.7
Downlink: 746-756 36.3 -25.8* 17.6 43.4
*Input power level is decreased before reaching AGC -0.5 dB to maintain compliance with the intermodulation product of -13 dBm.
Mean power: Measurements obtained on section 6.2 where Pmean = P01+3dB
