INSTALLATION
STEP 1 ACTUATOR
TOOLS REQUIRED:
1. 5/32" hex wrench
PARTS REQUIRED:
A. Rear strut assembly
B. Actuator
C. 1/4" hex cap screws
Slide the rear strut assembly (A) over actuator rear receiver handle (B). Secure rear strut using 1/4" hex cap screws
(C), tighten with 5/32" hex wrench.
NOTE: Images used in this document are for reference only when assembling, installing and/or operating this product.
Actual appearance of provided and/or purchased parts and assemblies may dier.
REPEAT STEP FOR THE SECOND ASSEMBLY
