13-10 AY50K4/WK4 (’04-MODEL)
ELECTRICAL
Unit: mm
WATTAGE Unit: W
ITEM SPECIFICATION NOTE
Spark plug
Type
NGK: BPR6HS
DENSO: W20FPR
Gap 0.6 – 0.7
Spark performance Over 8 at 1 atm.
Ignition coil resistance
Secondary 4 – 10 kΩ
Plug cap –
B/W lead wire
terminal
Generator coil resistance Charging 0.2 – 1.5 Ω Y – Ground
Pick-up 100 – 270 Ω R – Ground
Regulated voltage 13.5 – 15.5 V at 5 000 r/min
Generator Max. output 100 W at 5 000 r/min
Starter relay resistance 50 – 90 Ω
Battery Type
designation
YT4L-BS
Capacity 12 V 10.8 kC (3 Ah)/10 HR
Fuse size 10 A
ITEM SPECIFICATION
Headlight HI 35
LO 35
Brake light/Taillight 21/5
Turn signal light 10
License plate light 5
Speedometer light 1.2 × 2
Fuel meter light 1.2
Turn signal indicator light 2
Oil level indicator light 2
Water temp. indicator light 2
High beam indicator light 1.2
Trunk light 2
