AY50K4/WK4 (’04-MODEL) 13-11
BRAKE + WHEEL
Unit: mm
SUSPENSION
Unit: mm
TIRE PRESSURE
ITEM STANDARD/SPECIFICATION LIMIT
Brake disc thickness Front 4.0 ± 0.2 3.5
Rear 4.0 ± 0.2 3.5
Brake disc runout Front &
Rear
—0.30
Master cylinder bore Front 11.000 – 11.043 —
Rear 12.000 – 12.043 —
Master cylinder piston diam. Front 10.957 – 10.984 —
Rear 11.957 – 11.984 —
Brake caliper cylinder bore Front 30.230 – 30.306 —
Rear 30.230 – 30.306 —
Brake caliper piston diam. Front 30.150 – 30.200 —
Rear 30.150 – 30.200 —
Brake fluid type DOT 4 —
Wheel rim runout Axial — 2.0
Radial — 2.0
Wheel axle runout Front — 0.25
Wheel rim size Front J12 × MT3.50 —
Rear J13MC × MT3.50 —
Tire size Front 120/70-12 51L —
Rear 130/60-13 M/C 53L —
Tire type Front METZELER: ME 7 TEEN —
Rear METZELER: ME 7 TEEN —
Tire tread depth Front — 1.6
Rear — 1.6
ITEM STANDARD LIMIT
Front fork stroke 77 —
Front fork spring free length 124.7 122
Rear wheel travel 60 —
COLD INFLATION
TIRE PRESSURE
SOLO RIDING DUAL RIDING
kPa kgf/cm
2
psi kPa kgf/cm
2
psi
FRONT 125 1.25 18 125 1.25 18
REAR 175 1.75 25 230 2.30 33
