61
SPECIFICATIONS
Power rated in accordance with NMMA procedure.
CHART OF TOTAL OPERATING HOURS INDICATION
*: One flashing is corresponded to 500 hours.
Item DF100A DF115A DF140A
Engine Type 4 Stroke
Number of Cylinders 4
Bore and Stroke 86.0 × 88.0 mm (3.39 × 3.46 in.)
Piston Displacement 2044 cm
3
(124.7 cu. in.)
Maximum output 73.6 kW (100PS) 84.6 kW (115PS) 103.0 kW (140PS)
Full Throttle Operating Range 5000 – 6000
r/min. (min
–1
)
5000 – 6000
r/min. (min
–1
)
5600 – 6200
r/min. (min
–1
)
Idle speed (in Neutral) 700 ± 50 r/min. (min
–1
)
Ignition System Full-transistor
Engine Lubrication Trochoid pump pressure lubrication
Engine Oil Capacity 5.5 L (5.8/4.8 US/lmp qt)
Tot al
operating
hours
MONITOR-TACHOMETER
Needle 1
indication
REV-LIMIT
lamp 2 flashing *
0h-(49h) No No
50h- 500rpm
No
60h- 600rpm No
:
:
:
:
:
:
540h- 5400rpm No
550h- 500rpm 1 time
560h- 600rpm 1 time
:
:
:
:
:
:
1040h- 5400rpm 1 time
1050h- 500rpm 2 times
:
:
:
:
:
:
1540h- 5400rpm 2 times
1550h- 500rpm 3 times
:
:
:
:
:
:
2030h- 5300rpm 3 times
2040h or over 5400rpm 3 times
