Suzuki SV1000 - Brake Pedal;Footrest Set-Up

SV1000K3 15
BRAKE PEDAL/FOOTREST SET-UP
Pin
E-ring
Spacer
Spring
Footrest bracket
Brake return spring
Brake light switch spring
A
A
Brake pedal
Rear brake master cylinder
Cotter pin
SECT A
E-ring
Footrest
Footrest holder
Brake pedal
Footrest bracket
SECT B
B
B
Rear brake reservoir tank bracket
