SV 103 User Guide
SV 103 Technical Specification
The policy of our company is to continually innovate and develop our products.
Therefore, we reserve the right to change the specifications without prior notice.
Application Hand-arm
Standards ISO 8041:2005, ISO 5349-1:2001; ISO 5349-2:2001;
Meter Mode ahw (RMS), ahv (VECTOR), Max, Peak, Peak-Peak
A(8) Daily Exposure, ELV Time (TIME LEFT TO LIMIT),
EAV Time (TIME LEFT TO ACTION)
Filters W
h
(ISO 5349) and corresponding Band Limiting filter
RMS & RMQ Detectors Digital true RMS detector with Peak detection, resolution 0.1 dB
Measurement Range 0.2 ms
-2
RMS ÷ 2000 ms
-2
PEAK
Frequency Range 1 Hz ÷ 2000 Hz
Data Logger Time-history data including meter mode results and spectra
Time-Domain Recording Simultaneous 3-channel time-domain signal recording (option)
Analyser 1/1 octave real-time analysis (option)
1/3 octave real-time analysis (option)
Accelerometer Detachable SV 107 tri-axial accelerometer with hand straps in accordance to ISO 5349
Display OLED 128 x 32 pixels
Memory 8 GB
Interfaces USB 2.0 client, Bluetooth
Keyboard 4 push buttons
Power Supply
Ni-MH rechargeable cells operation time > 24 hours
1
USB interface 500 mA HUB
Environmental Conditions
Temperature from -10
o
C to 50
o
C
Humidity up to 90 % RH, non-condensed
Dimensions 88 x 49.5 x 19.2 mm (instrument without accelerometer, cable and mounting stripe)
Weight 150-160 grams with SV 107 accelerometer and one of
vibration contact adapters
1
dependent on instrument operation configuration
