Section IV: Maintenance
4.0.MAI.SL
-
160
ADJUSTMENT
Should the jib lockout valve need adjustment the first step will be to loosen the mount bracket
screws (see illustration above). Reposition the jib lockout valve with respect to the valve ramp
by turning the adjustment screw on the valve mount bracket as follows:
Clockwise Adjustment – Moves the jib lockout valve closer to the valve ramp
Counter-Clockwise Adjustment – Moves the jib lockout valve away from the valve ramp
Once the valve has been moved back into proper adjustment, then tighten up the mount bracket
screws.
PART NUMBER & SPECIFICATION
SwapLoader
Pt. No.
Work Port Size Spool Type
21P28 3/4-16 ORB (SAE 8) 2-Way, 2-Position N.C.
Please contact your SwapLoader Distributor or SwapLoader USA should you have any
questions regarding this procedure.
