Section V: Parts
5.0.PAR.SL-160
13H06 – PIVOT LOCK SUB-ASSEMBLY SL-160
ITEM
PART
#
QTY DESCRIPTION
WT-
lb/ea.
WT-
lb/all
1
13H24
2
Take Up Wdmt, 3/8-16UNCx4-1/2
0.21
0.42
2
25H7
6
1
Retainer, Lock Bar, SL-212
1.14
1.14
3
25H77
2
Spacer, Pivot Lock 1-1/8
0.10
0.20
4 25H78 1
Spring Plate, SL-212
0.98 0.98
5 27H05 1 Safety Latch Lever 4.75 4.75
6
27H06
1
Pivot Lock Bar
9.60
9.60
7
00P32
2
SHCS 3/8-16 UNC x 1-1/4
0.07
0.14
8
00P34
2
Nut, Lock 3/8-16
0.02
0.04
9
01P28
3
Washer, Lock, Disc 3/8 Pr
0.01
0.03
10
01P30
2
Washer, Lock, Disc 1/2 Pr
0.02
0.04
1
1
01P
48
2
HHCS 1/2-13 UNC x 3 Gr8
0.19
0.38
1
2
01P67
4
FHCS 1/4-20 UNC x 3/4 Brass
0.01
0.04
1
3
90
P04
2
Spring, Extension 7/8 OD x 6 Lg
0.40
0.80
1
4
91P21
2
Wear Pad, 1-1/4 x 1/2 x 3-1/2
0.09
0.18
DISC-LOCK WASHER
TORQUE SPECS
BOLT
SIZE
SAE GR 8
ASS’Y TORQUE
(FT
-
LBS)
3/8
50
7/16
80
1/2
120
5/8
230
3/4
380
7/8
400
1
400
5-5
