67
FABRIC
NEEDLE SIZE
POINT
Fine Knitwear
Woven Fabrics
Denim-light/medium
Terry
Densely Woven
Silk
Coated Fabrics/Cordura
Vinyl
Leather
Caps-Woven, Corduroy
Fleece
Knitwear/ Jersey
75/11
70/10
75/11
75/11
80/12
65/9
80/12
75/11
75/11
75/11 or 80/12
75/11 or 80/12
75/11
BALL
SHARP
SHARP
SHARP
SHARP
SHARP
SHARP
SHARP
SHARP
SHARP
BALL
BALL
NEEDLE CHART
CHAPTER
11
71
73
Table of Contents
Default Chapter
4
Table of Contents
4
Chapter 1 Safety Rules
6
Delivery of Your Machine
7
Installation
8
Machine Operation
8
Troubleshooting
10
Placement of Warning Stickers
11
Chapter 2 Installation and Machine Assembly
12
Electricity
13
Leveling the Machine
14
Assembly of Peripheral Devices
15
Chapter 3 Parts of the Machine
21
Chapter 4 Functions and Features
22
Chapter 5 Button and Switch Operation
24
Chapter 6 Threading and Tension
26
The Upper Thread Path
26
Threading the Machine
27
Tension Control on Upper Thread
28
Take-Up Spring
29
Bobbin Threading and Tension Adjustment
30
Bobbin Winder
31
Chapter 7 The Needle, the Hook and the Stitches
33
Stitch Formation
33
The Needle and Hook
34
The Needle
34
Changing the Needle
36
Relationship between Needle and Hook
37
Relationship between Take-Up Lever and Hook
40
Thread-Break Detecting Unit
41
Chapter 8 Maintenance and Inspection
42
Oil Supply
44
Grease Supply
47
Chapter 9 Machine Adjustments
49
Chapter 10 Troubleshooting
62
Chapter 11 Needle Chart
72
Chapter 12 Backing
73
Chapter 13 Hooping and Tensions
74
