FITTED EQUIPMENT
138
Description of refrigerator
2
1
8
7
9
6
5
3
4
RMx 8xx0 / Battery igniter
RMx 8xx1 / MES
1
1
1
RMx 8xx5 / AES
Fig. 5
1 - Operating controls
2 - Door locking button
3 - Freezer compartment (removable)
4 - Insertable grid shelf (available as option,
to be used when freezer compartment is
removed)
5 - Post-evaporator for cooling compartment
6 - Condensation water drain channel
7 - Vegetable bin
8 - Upper door shelf with flap, egg shelf
available as option may be inserted
9 - Lower door shelf with bottle holders
DOMETIC REFRIGERATOR
