FITTED EQUIPMENT
169
Thetford C400 Cassette Toilet
These operating instructions cover Thetford
cassette toilet models C-402C, C-402X and
C-403L. There are a few differences in the use
of these models. Make sure that you follow the
instructions that apply to your toilet model.
The parts and functions that are referred to by
letters are illustrated in later pages.
The actions to be taken, referred to by
numbers, are illustrated are also illustrated in
pages 174-175.
Parts and functions
C-402C and C-402X
a. Handle: opens and shuts the valve blade
b. Flush knob: when this pressed, an electric
pump fills the bowl with water
c. Level indicator display: the red LED on the
display lights up when the waste tank is full
(C-402C and C-402X). When the flush know
is pressed briefly, the display shows the level
in the waste tank and the level in the water
tank (C-402X).
d. Removable seat and cover
e. Cover plates
f. Storage compartment for toilet fluids (only
the tall model)
g. Safety catch: holds the waste tank in place
h. Water filling tunnel: for easy filling of the
water tank.
i. Cover: guarantees optimal hygiene. Opens
when the waste tank is located in the toilet
and closes when the waste tank is removed.
j. Removable mechanism
k. Valve blade opener
l. Valve blade / valve seal
m. Vent plunger: for emptying with splashing.
n: Upper handle
o. Automatic pressure release valve: ventilates
the waste tank when this located in the
cassette toilet. Avoids excessive pressure in
the waste tank.
p. Pull-out handle: for easy transport of the
waste tank.
q. Wheels
r. Rotating emptying spout: ensures that the
waste tank can be easily and hygienically
emptied.
s. Water filling extension
t. Access hatch to waste tank and water
filling funnel: lockable from the outside of the
vehicle.
C-402L
a. Handle: opens and shuts the valve blade.
b Flush knob: when pressed a central
electric pump in the vehicle pumps water
into the bowl.
c. Level indicator display: the red LED on the
display lights up when the waste tank is full.
When the flush knob is pressed briefly, the
display shows the level in the waste tank.
d. Removable seat and cover
e. Cover plate
f. Storage compartment for toilet fluids (only
the tall models)
g. Safety catch: holds the waste tank in place.
h. Cover: guarantees optimal hygiene. Opens
when the waste tank is located in the toilet.
i. Removable mechanism
j. Valve blade opener
k. Valve blade / Valve seal
l. Vent plunger: for emptying without splashing.
m. Automatic pressure release vent: ventilates
the waste tank when this is located in the
cassette toilet. Avoids excessive pressure in
the waste tank.
n. Upper handle: for easy emptying
o. Pull-out handle: for easy transport of the
waste tank.
p. Wheels
