FITTED EQUIPMENT
146
Frame heating
All models are equipped with a frame
heating (12VDC/3,5W) around the freezer
compartment. During summer months with
high temperatures and humidity the metal
frame may have water droplets forming. To
evaporate these droplets switch on the frame
heating with button (6).
Fig. 18
6
8
The operating time of the frame heater can
be set to 2 hours, 5 hours or continuous
operation. After selecting the operating time
using the button (6), the temperature level
indicator (8) is extinguished for a short time to
show the set operating time for a few seconds.
The display then returns to the temperature
level indicator.
Operating time: 2 hours
Press button (6) once Display
1x
Operating time: 5 hours
Press button (6) twice Display
2x
Permanent Operation
Press button (6) three times Display
3x
! WARNING: In order to prevent discharge
of the onboard battery, change the frame
heater from continuous operation to another
operating time or switch it off.
Note: The frame heater is active for 30
minutes after switching on and then
switches itself off and on again at time
intervals of 5 minutes.
Refrigerator compartments
5
1
6
7
2
3
4
Fig. 37
1 - Freezer compartment :
already frozen food (deep-frozen food)
2 - Middle compartment:
Dairy products, convenience food
3 - Bottom compartment:
Meat, fish, food for defrosting
4 - Vegetable compartment:
Salads, vegetables, fruit
5 - Top door shelf:
Eggs, butter
6 - Middle door shelf:
Cans, dressings, ketchup, jam
7 - Bottom door shelf (drinks compartment):
Drinks in bottles or bags
Removable freezer compartment
Fig. 32
DOMETIC REFRIGERATOR
