ELECTRICS
74
The following table shows the fuse allocation
for the 15 fuses fitted to the PSU. Please note
that fuses are dependant on PSU versions, so
not all fuses may be present.
Fuse Rating Fuse colour Description
1 20 Amps Yellow * Motorhome Fridge 12V
2 15 Amps Blue * Motorhome Towing
3 7.5 Amps Brown * Motorhome Marker Lights
4 15 Amps Blue * Motorhome Fridge D+
5 10 Amps Red Extractor Fans / Heating Systems
6 10 Amps Red 12V Sockets / TV Amp / ***Radio
7 10 Amps Red Front Internal Lights
8 10 Amps Red Water Pumps / Toilet
9 15 Amps Blue * Electric Step
10 10 Amps Red * Motorhome Tank Heaters
11 10 Amps Red ** Auxiliary Supplies
12 5 Amps Tan Electronics / Fridge / Alarm
13 5 Amps Tan Oven Ignition / * Water Heater
14 10 Amps Red Rear Internal Lights
15 25 Amps Clear Charger (fitted internally to PSU)
* Where Applicable / When Fitted
** Motorhome Awning / Entry lights / Map
lights / Enroute Heating / Compressor Fridge
/ Travel Skts
*** Motorhome Bathroom lights
The following table shows details of the fuse(s)
located at the Leisure battery. See also 3.4A
Fuse Rating Fuse colour Description
Battery 1 20 Amps Yellow Fuse remotely located near battery
Battery 2 20 Amps Yellow Fuse remotely located near battery 2
(where fitted)
EC400 SERIES POWER SUPPLY SYSTEM
