Swift S7 Series User Manual

3
Diopter adjustment
On left and right tubes, +/-5
Magnification range
(standard model)
7X-45X
Focusing travel range
50mm
Working distance
(standard)
100mm
C-mount adapter
--
Trinocular head only
--
0.5X, 1X adapters available
Available additional
auxiliary objectives
0.5X (WD = 165mm)
2.0X (WD = 30mm)
Illumination options
56-bulb LED ring light, 6000-7000K, 100-240V
144-bulb LED ring light, 6000-7000K, 100-240V
Stand options
Plain stand
Single-arm boom stand
Dual-arm boom stand
S7 Series optics specifications
Eyepiece
Standard
configuration
Optional auxiliary objectives
0.5X
2X
WD 100mm
WD 165mm
WD 30mm
Mag.
FOV (mm)
Mag.
FOV (mm)
Mag.
FOV (mm)
