Sandfiltersystem Basic 3
4.2 Filling of filter sand
Open the locking ring at the filter tank's opening and take off the filter lid. Having done this, check
that the bottom plate and the separator wall inside the filter tank are correctly positioned. Note that
the bars on the bottom plate continue to the bars of the filter tank's inner wall. Thereafter, the
separator plate should also be placed in these wire bars so that the upper edge of the separator plate is
lying flat against the top edge of the filter tank. See photos 4.2a and 4.2b.
Photo 4.2c Photo 4.2d
Observe: In order to protect the filter tank and the bottom plate against possible damage,
ALWAYS fill the filter tank with 20 cm of water before the filter sand is poured into the
tank! Photo 4.2c + 4.2d.
(A plastic clamp is included for tightening the
pressing ring)
Swim & Fun Scandinavia – info@swim-fun.com – www.swim-fun.com 8
