Swiss Timing MULTISPORTS E-GUN - Electrical Properties; Power Supply; Connectors Pinning

E-GUN / StartTime IV
Version 1.1 3481.501.02 Page 17
4 ELECTRICAL PROPERTIES
4.1 Power supply
Use only charger supplied or a type approved by .This could destroy the battery,
cause damage to unit, and possible cause personal injury due to fire or/and electrical shock.
4.2 Connectors pinning
Description Connector type Pin Pin description
MICROPHONE
E-GUN
UTG / UTS 8pFT
A
RS485 – serial line
B
RS485 + serial line
C
CmdFlash-
D
GND (Signal)
E
Power +12VDC
F
GND (Power)
G
Line - audio
H
Line + audio
START 1
START 2
Tuchel 4pMT
1 Ready signal from TIMER (-)
2 Start to TIMER
3 Start to TIMER
4 Ready signal from TIMER (+)
FLASH
Tuchel 4pFT
1 Power feed for Flash (+12V)
2 Start Out Flash
3 Start Out Flash
4 Power feed for Flash (0V)
SPEAKER
Tuchel 4pFT
1 Speaker Plus (+) of Amplifier #1
2 Speaker Minus (-) of Amplifier #1
3 Speaker Plus (+) of Amplifier #2
4 Speaker Minus (-) of Amplifier #2
LINE OUT
XLR 3pMT
1 GND
2 Balanced line +
3 Balanced line -
CHARGER
Tuchel 3pMT
1 Battery (+)
2 Not used
3 Battery (-)
