Swiss Timing MULTISPORTS E-GUN - Start & Microphone Unit (SMU)

E-GUN / StartTime IV
Version 1.1 3481.501.02 Page 3
1.3 Start & Microphone unit (SMU)
SPEAK
Allow starter to connect microphone to
loudspeaker output or TEL line
START
Allow starter to start the TIMER
READY 1
Ready status of TIMER 1
READY 2
Ready status of TIMER 2
RECALLERS 1-3
Status of starter recaller (AT)
External microphone
External headset
Figure 2 – SMU
