WorkingPro™ 400 & 700
(This is the model name for warranty claims)
* Non-serviceable part. Replace complete parent assembly. See PCB EXCHANGE POLICY above.
shaded Unique Fender® part. Order directly from the FMIC Parts Department.
shaded + * Access to this part or assembly is controlled. Please contact the FMIC Customer Service Department.
** Safety Requirement part. Replacement must match Safety Agency…–Value, if specified –Type, if specified –Approval Mark(s) if on part.
shaded +** Both a unique Fender® part and a Safety Requirement part as defined above.
9
PARTS LIST:
I/O REAR PANEL – PCB ASSEMBLY
(Rev B)
QTY. PART # DESCRIPTION REFERENCE DESIGNATION
*1 006474900x PCB ASSY WORKINGPRO I/O
REF 0064747000
SVC DIA COMB. WORKINGPRO AMPS
1 0028467003 CAP AE RDL 22uF 50V 20% C204
2 0047195003 CAP AE RDL 47uF 63V 20% C210 C212
1 0051457003 CAP CD 100pF 500V 5% C211
1 0051960003 CAP CD 180pF 500V 10% C213
7 0051406003 CAP CD 220pF 500V 10% C202-203 C205-209
1 0051458003 CAP CD 470pF 500V 10% C201
1
0065388000 CONNECTOR DIN VERT PCB 5 PIN FEMALE J202
1
0006260001 DIODE 1N4448 SIGNAL D201
2 0065442000 HDR .1 CTR 8 CKT RT ANG LOCKING P201-202
1 0031611000 IC OP-AMP DUAL PC4560 U201
1 0016795000 IC OP-AMP DUAL TL072 U202
2 0066431000 JACK 1/4" MONO PASSIVE J204-205
1 0030771000 JACK 1/4 PCB 2/CD SCC J206
1 0051007000 JACK 1/4 PCB STEREO W/ SWITCH J201
1 0066432000 JACK1/4"STPLST NON-SHORTNG J203
3 0024969001 RES CF 1/4W 5% 1.5k LL R210 R213 R216
3 0024981001 RES CF 1/4W 5% 10k LL R203 R209 R212
2 0024965001 RES CF 1/4W 5% 1k LL R207 R217
2 0024977001 RES CF 1/4W 5% 4.7k LL R206 R215
4 0024947001 RES CF 1/4W 5% 47ohm LL R201-202 R204-205
2 0024961001 RES CF 1/4W 5% 470ohm LL R214 R218
3 0050817000 SWITCH PB PC VERT MNT DPDT S201-203
3 0065385000 BUTTON SWITCH ROUND GRAY @S201-203
3 0065384000 EXTENSION BUTTON 2.8mm SHAFT @S201-203
1 0049892000 XLR CONNECTOR MALE GOLD J207
2 0014689003 XSTR N-CH JFET J111 TO-92 Q201-202
1 0065591000 CABLE RIBBON 5 COND 2" @P203-204
To Next Page
