WorkingPro™ 400 & 700
(This is the model name for warranty claims)
* Non-serviceable part. Replace complete parent assembly. See PCB EXCHANGE POLICY above.
shaded Unique Fender® part. Order directly from the FMIC Parts Department.
shaded + * Access to this part or assembly is controlled. Please contact the FMIC Customer Service Department.
** Safety Requirement part. Replacement must match Safety Agency…–Value, if specified –Type, if specified –Approval Mark(s) if on part.
shaded +** Both a unique Fender® part and a Safety Requirement part as defined above.
13
PARTS LIST:
CHASSIS ASSEMBLY
(Rev C)
QTY. PART # DESCRIPTION REFERENCE DESIGNATION
*1 0064746000 PCB ASSY,WORKINGPRO PREAMP
*1 0064749000 PCB ASSY, WORKINGPRO I/O
*1 0064752000 PCB ASSY, WORKINGPRO SPKR OUT
*1 0064753000 PCB ASSY PWR SPLY WORKINGPRO
2 9904300100 WASHER LCK INTL 3/8X.681X.032 @ speaker jacks
2 0066374000 HANDLE OVAL CHROME
4 0066500000 SCRW M 10-32x1/2 FHP BLX @ handles
1 0047213000 CONNECTOR AC LINE MALE IEC
3 0069393000 NUT 6-32 HEX EXT LOCK GND, Regulator, Input GND
12 0041602000 SCRW M 6-32x3/8 FHP BLX Top Cover, IEC
4 0070633000 SCRW M 6-32x3/8 FHP BLX W/NYLON PATCH Power module mount
8 0065589000 MACH SC 8-32X3/8 SHCS B/OX @ Front Panel
4 0055743400 RUBBER FOOT 11/16"IA 240001
4 0017433000 SCRW M 6-32x3/8 PHP BLX @ feet
8 0031184000 SCRW M 6-32x1/4 PHP BLX ITLW @ output PCB, PS PCB, DIN
2 0051155000 SCRW SMB 4x3/8 PHP BLX @ XLR jack
1 0022004000 NUT KEPS #8-32 ZINC @ bridge rectifier
1 0053910000 SCRW M 1/4-20x3 CAR BLX xfmr mount
1 9904300900 WASHER FLAT 1/4X1 STL BLX xfmr mount
1 0028272000 NUT KEP 1/4x20 FOJ xfmr mount
*1 0065926000 BADGE SWR "HUBCAP" SMALL
2 0067098000 SPEED NUT PUSH ON TYPE SMALL
11 0066453000 KNOB BLACK PUSH-ON 18 TOOTH
1 0065395000 CABLE ASSY CRIMP 8 CKT 14" RED
1 0065389000 CABLE ASSY CRIMP 8 CKT 14" GRN
1 0065396000 CABLE ASSY CRIMP 9 CKT 15" BLK
1 0067122000 SWITCH ROCKER 15 A (100/120V models)
- 0068325000 SWITCH ROCKER SPST 16A EURO (230/240V models)
1 REF WIRESET CHASSIS WORKINGPRO AMPS
* LABEL, NORDIC (230/240V models)
Items Below are for WorkingPro 400 Chassis Assy
*1 0064714000 MODULE ASSY SWR500 PWR AMP
1 0064821000 **XFMR SWR 400 W AMPS 120V 60Hz (120V models)
0064822000 **XFMR SWR 400 W AMPS 230/240V 50Hz (230/240V models)
0064823000 **XFMR SWR 400 W AMPS 100V 50Hz (100V models)
0036703000 **FUSE HOLDER 5MM FINGER GRIP
1 0013684000 **FUSE TD 20mmx5mm 250v 8A (100/120V models)
0013679000 **FUSE TD 20mmx5mm 250v 4A (230/240V models)
* LABEL FUSE T4A 250V (230/240V models)
Items Below are for WorkingPro 700 Chassis Assy
*1 0064754000 MODULE ASSY SWR1000 PWR AMP
- 0064817000 **XFMR TOROID SWR 750W 230/240V 50 Hz (230/240V models)
1 0064818000 **XFMR TOROID SWR 750W 120V 60 Hz (120V models)
- 0064819000 **XFMR TOROID SWR 750W 100V 50 Hz (100V models)
1 0036702000 **FUSE HOLDER 3AG FINGER GRIP (100/120V models)
1 0032028000 **FUSE TD 1-1/4x1/4 250v 15A (100/120V models)
1 * LABEL FUSE T15A 250V (100/120V models)
- 0036703000 **FUSE HOLDER 5MM FINGER GRIP (230/240V models)
- 0013684000 **FUSE TD 20mmx5mm 250v 8A (230/240V models)
1 * LABEL WATTAGE "1440W"
1 * LABEL WATTAGE "700W"
