SWR WorkingPro Series Service Manual

WorkingPro™ 400 & 700
(This is the model name for warranty claims)
* Non-serviceable part. Replace complete parent assembly. See PCB EXCHANGE POLICY above.
shaded Unique Fender® part. Order directly from the FMIC Parts Department.
shaded + * Access to this part or assembly is controlled. Please contact the FMIC Customer Service Department.
** Safety Requirement part. Replacement must match Safety Agency…–Value, if specified –Type, if specified –Approval Mark(s) if on part.
shaded +** Both a unique Fender® part and a Safety Requirement part as defined above.
12
PARTS LIST: POWER AMP – PCB ASSEMBLY (Rev D)
QTY. PART # DESCRIPTION REFERENCE DESIGNATION
2 0025752003 XSTR PNP 2SA1038STPS Q8 Q17
1 0051447003 XSTR PNP 2SB1236 Q26
8 0014866003 XSTR PNP MPSW92 TO-226AE Q3-7 Q9 Q29-30
1 0028759000 XSTR PNP 2SA1306A TO-220P Q25
PARTS LIST: POWER MODULE ASSEMBLY (Rev C)
QTY. PART # DESCRIPTION REFERENCE DESIGNATION
*1 0064714000 MODULE ASSY SWR500 PWR AMP
*1 0064754000 MODULE ASSY SWR1000 PWR AMP
*1 0064548000 PCB ASSY SWR500/1000 PWR AMP
8 0031184000 SCRW M6-32X1/4 PHPS BLX ITLW @ PCB standoffs
1 0070539000 TUNNEL HEATSINK TOP SWR1000 PWR AMP
1 0070540000 TUNNEL HEATSINK BOTTOM SWR1000 PWR AMP
1 0064607000 HEATSINK SWR500/1000 PWR AMP
1 0065393000 FAN SWR500/1000 PWR AMP
4 0065473000 SCRW SMA #8x2" HWHS ZI fan mount
1 0065391000 SPACER FOAM SWR500/100 PWR AMP
1 0068817000 XSTR NPN MJE15034 TO-220 Q35
1 0068818000 XSTR PNP MJE15035 TO-220 Q44
2 0017746000 WSHR SHLDR NYL 1/8x1/4 @ Q35, Q44
2
0068819000
INSULATOR SILICONE TO-220 NAR @ Q35, Q44
1 0028760000 XSTR NPN 2SC4793/2SC3298B Q34
6 0027638000 SCRW TF 4-40x 3/8 HWHS ZI .1" @ driver xstrs, tunnel, & thermistor
Items Below are for SWR500 Power Module Assy #0064714000, used in WorkingPro 400
3 0054804000 XSTR NPN 2SC2922 MT-200 Q36-38
3 0054805000 XSTR PNP 2SA1216 MT-200 Q40-42
6 0065390000 INSULATOR SILICONE MT-200 @ Q36-38, Q40-42
15 0032937000 WSHR CONE @ Q34, Q36-38, Q40-42
12 0032934000 SCRW TF 4-40x1/2 HWHS ZI .1" @ Q36-38, Q40-42
Items Below are for SWR1000 Power Module Assy #0064754000, used in WorkingPro 700
4 0066778000 XSTR NPN 2SC3264 MT-200 Q36-39
4 0068373000 XSTR PNP 2SA1295 MT-200 Q40-43
8 0065390000 INSULATOR SILICONE MT-200 @ Q36-39, Q40-43
19 0032937000 WSHR CONE @ Q34, Q36-39, Q40-43
16 0032934000 SCRW TF 4-40x1/2 HWHS ZI .1" @ Q36-39, Q40-43
