WorkingPro™ 400 & 700
(This is the model name for warranty claims)
* Non-serviceable part. Replace complete parent assembly. See PCB EXCHANGE POLICY above.
shaded Unique Fender® part. Order directly from the FMIC Parts Department.
shaded + * Access to this part or assembly is controlled. Please contact the FMIC Customer Service Department.
** Safety Requirement part. Replacement must match Safety Agency…–Value, if specified –Type, if specified –Approval Mark(s) if on part.
shaded +** Both a unique Fender® part and a Safety Requirement part as defined above.
11
PARTS LIST:
POWER AMP – PCB ASSEMBLY
(Rev D)
QTY. PART # DESCRIPTION REFERENCE DESIGNATION
1 0013562000 IC REGULATOR +15V MC7815CT U2
1 0013564000 IC REGULATOR -15V MC7915CT U1
2 0050849000 HEATSINK PCB LEVEL 576012U @ U1-2
2
0017974000
INSULATOR MICA TO-220
@ U1-2
3 0097360000 NUT HEX 4-40 EX LOCk @ U1-2 Q25
3 0039420000 SCRW M 4-40x3/8 PHP SS ITLW @ U1-2 Q25
2 0017746000 WSHR SHLDR NYL 1/8x1/4 @ U1-2
2 REF JUMPER WIRE 22 GA W1-2
1 0027387000 INDUCTOR AIR CORE RDL 2.5uH L1
1 0029557001 RES CF 1/4W 5% 1 ohm LL R68
1 0024969001 RES CF 1/4W 5% 1.5k LL R88
5 0024997001 RES CF 1/4W 5% 100k LL R5 R31 R35 R39 R84
3 0024981001 RES CF 1/4W 5% 10k LL R18 R32 R38
4 0024937001 RES CF 1/4W 5% 10ohm LL R3 R6 R83 R90
1 0029002001 RES CF 1/4W 5% 11k LL R89
1 0024985001 RES CF 1/4W 5% 15k LL R42
6 0024965001 RES CF 1/4W 5% 1k LL R4 R15 R25 R29 R49 R74
2 0025069001 RES CF 1/4W 5% 1M LL R28 R33
3 0024971001 RES CF 1/4W 5% 2.2k LL R78-79 R87
2 0024972001 RES CF 1/4W 5% 2.7k LL R27 R75
3 0024988001 RES CF 1/4W 5% 27k LL R12 R26 R30
1 0024977001 RES CF 1/4W 5% 4.7k LL R20
1 0025065001 RES CF 1/4W 5% 470k LL R41
2 0024961001 RES CF 1/4W 5% 470ohm LL R37 R72
2 0024993001 RES CF 1/4W 5% 47k LL R19 R76
1 0024962001 RES CF 1/4W 5% 560ohm LL R86
1 0024994001 RES CF 1/4W 5% 56k LL R36
1 0028948001 RES CF 1/4W 5% 6.2k LL R73
1 0024963001 RES CF 1/4W 5% 680ohm LL R77
2 0048903001 RES CF 1/2W 5% 18k LL R46 R69
1 0027627001 RES FILM 1W 5% 10ohm LL R1
1 0064459001 RES MF 1/4W 1% 1.69k LL R47
1 0064515001 RES MF 1/4W 1% 316ohm LL R44
1 0016946001 RES MF 1/4W 1% 825ohm LL R48
1 0056577001 **RES MOX FP 1/4W 5% 100ohm LL R71
2 0068848000 **RES MOX FP 1/4W 5% 10k LL R7 R80
4 0068847000 **RES MOX FP 1/4W 5% 1k LL R8-9 R81-82
4 0068719001 **RES MOX FP 1/4W 5% 220ohm LL R2 R23 R45 R66
8 0068846000 **RES MOX FP 1/4W 5% 4.7ohm LL R54-58 R61 R64-65
6 0051040001 **RES MOX FP 1/4W 5% 47ohm LL R10-11 R14 R16-17 R21
2 0068720001 **RES MOX FP 1/4W 5% 470ohm LL R22 R24
8 0055932001 RES MOX 2W 5% .15ohm LL R50-53 R59-60 R62-63
2 0027628001 RES MOX 2W 5% 47ohm LL R34 R43
2 0069305000 RES MOX 5W 5% 10Ω W/STANDOFF
R67 R85
1 0065472000 **THERMISTOR 10kOhm 5.5" LEADS TC1
1 REF WIRESET PCB SWR500/100 PWR AMP @WJ1
4 0016739003 XSTR NPN 2N4401 TO-92 Q18 Q20 Q22-23
4 0025751003 XSTR NPN 2SC2362K/2SC2389STPS Q10 Q14-16
7 0014867003 XSTR NPN MPSW42 TO-226AE Q1-2 Q11-13 Q27-28
1 0051448003 XSTR NPN 2SD1857 Q24
5 0016742003 XSTR PNP 2N4403 TO-92 Q19 Q21 Q31-33
