WorkingPro™ 400 & 700
(This is the model name for warranty claims)
* Non-serviceable part. Replace complete parent assembly. See PCB EXCHANGE POLICY above.
shaded Unique Fender® part. Order directly from the FMIC Parts Department.
shaded + * Access to this part or assembly is controlled. Please contact the FMIC Customer Service Department.
** Safety Requirement part. Replacement must match Safety Agency…–Value, if specified –Type, if specified –Approval Mark(s) if on part.
shaded +** Both a unique Fender® part and a Safety Requirement part as defined above.
10
PARTS LIST:
SPEAKER OUT – PCB ASSEMBLY
QTY. PART # DESCRIPTION REFERENCE DESIGNATION
*1 0064752000 PCB ASSY WORKINGPRO SPKR OUT
2 0067388000 CONNECTOR SPEAKON PC MT VERT J302 J304
2 0029175000 JACK PHONE 1/4" HI CURRENT PC J301 J303
PARTS LIST:
POWER SUPPLY – PCB ASSEMBLY
QTY. PART # DESCRIPTION REFERENCE DESIGNATION
*1 0064753000 PCB ASSY WORKINGPRO PWR SPLY
1 0065173000 BRIDGE RECTIFIER 40A 400V I/L
2 0053915000 CAP AE RDL 10000uF 100V C401-402
1 0053860000 **CAP MPF .1uF 275V 10% C6
1 0024853000 CAP MPF RDL .1uF 250V 10% C5
2 0025116000 RES CF 1/2W 100k 5% R1-2
1 0026411000 **THERMISTOR 2.5 ohm 8A C30-19 RT1
PARTS LIST:
POWER AMP – PCB ASSEMBLY
(Rev D)
QTY. PART # DESCRIPTION REFERENCE DESIGNATION
*1 0064548000 PCB ASSY SWR500/1000 PWR AMP
REF SVC DIA COMB SWR 500/1000 PWR AMP
1 0038692000 CAP AE AX 10uF 35V 20% C13
3 0068838000 CAP AE RDL 2200uF 35V LP 105C C17-18 C29
1 0028458003 CAP AE RDL 1uF 50V 20% C5
4 0028460003 CAP AE RDL 4.7uF 50V 20% C19-20 C22 C24
1 0028471003 CAP AE RDL 47uF 50V 20% C10
2 0025787003 CAP AE RDL MINI 100uF 16V NP C1 C3
2 0039270001 CAP CA .01uF 50V C6 C21
4 0038703001 CAP CA .1uF 50V C16 C23 C25-26
1 0038703001 CAP CD 10pF 1000v 10% C8
2 0051445003 CAP CD 22pF 500V 5% C2 C4
2 0027261003 CAP MPF .0047uF 100V 10% C30-31
6 0051416003 CAP SF .1uF 100V 10% C9 C11 C14-15 C27-28
8 0064089001 DIODE 1N4003 D19-24 D29 D34
23 0006260001 DIODE 1N4448 SIGNAL
D1 D3-10 D13-15 D17-18 D25-28 D30-32 D35-36
2 0025821001 DIODE HV FDH400 SWITCHING LL D2 D11
1 0031017001 DIODE ZEN 1N5223B 2.7V 5% LL D33
1 0031018001 DIODE ZEN 1N5239B 9.1V 5% LL D37
2 0031635001 DIODE ZEN 1N5240B 10V 5% LL D12 D16
2 0070334001 **FUSE QA AXIAL LEAD 7A 125V F1-2
1 0054303000 CABLE RIBBON 10CKT 7.5" P2
1 0027419000 HDR .1 CTR 10 CKT SQ PIN P10
2 0027408000 HDR .1 CTR 2 CKT SQ PIN P12
1 0027418000 HDR .1 CTR 9 CKT SQ PIN PW1
1 0027410000 HDR .1 CTR 3 CKT SQ PIN P13
