6. Control elements and connections
a) Indoor unit
1 Colour display
2 Button “„ ”
3 Button “ ”
4 Button “ ”
5 Button “ ”
6 Button “ ”
7 Button “ ”
8 Button “ ”
9 Setting controller for volume
10 Screws to attach the indoor unit to the wall holder
11 Microphone
12 Screw terminals
13 DIP-switch for master/slave
14 Wall holder
15 Speaker
