12. Specifications
Measurement range: 12.5mm 12.5mm
Resolution 0.01mm 0.001mm
Max error 10µm +1 digit 4µm
Repeatability: 2µm
Weight: 75g
Measurement force (standard) +20% : 0.5-0.9N 0.5-0.9N
Measurement force (protected) +20% : 0.6-1.3N 0.6-1.3N
Max. speed of travel: 1.7m/s
No. of measurements / second:
up to 10 meas/s MIN/MAX mode: up to 20 meas/s
Measurement unit: metric/english (Inch)
Maximum Preset (10µm resolution):
±999.99 mm / ±39.9995 IN ±99.999 mm / ±3.99995 IN
Measurement system: Sylvac inductive system (patented)
Power: 1 x 3V lithium battery, type CR2032, 220mAh
Average battery life: 8’000 hours (with
Bluetooth
®
enabled, see chapter 5.1)
Data output: RS232 compatible / Bluetooth
®
4.0 (see chapter 5)
Working temperature (storage): +5 to +40°C (-10 to +60°C)
Electromagnetic compatibility: as per EN 61326-1
IP rating (in accordance with IEC60529): IP 67
Fixing and space envelope: Ø8h6 (3/8’’), interchangable M2.5 (4-48-UNF) probe (as per DIN 878)
17
