Sylvania 6620LCT A - Mechanical Parts List

20060322 12-1 L3219CA
MECHANICAL PARTS LIST
PRODUCT SAFETY NOTE: Products marked with a
# have special characteristics important to safety.
Before replacing any of these components, read
carefully the product safety notice in this service
manual. Don't degrade the safety of the product
through improper servicing.
NOTE: Parts that are not assigned part numbers
(---------) are not available.
Comparison Chart of Models and Marks
Model Mark
6620LCT A
6620LG B
Ref. No. Mark Description Part No.
A1 A FRONT CABINET L2600UA 1EM020908
A1 B FRONT CABINET L3223UD 1EM121534
A3 CONTROL PLATE L2500UA 1EM321811
A4 REAR CABIET L2600UA 1EM020948
A6# A RATING LABEL L3219UK ----------
A6# B RATING LABEL L3223UD ----------
A7 FUNCTION KNOB L2500UA 1EM220762
A9 A TILT STAND ASSEMBLY L3219UK 1ESA12971
A9 B TILT STAND ASSEMBLY L3223UD 1ESA13060
A9-1 A STAND COVER L3219UK 1EM021330
A9-1 B STAND COVER L3124UG 1EM221329
A9-2 ARM HOLDER L3219UK 1EM221304
A9-3 ARM ASSEMBLY L3219UK 1EM221283
A9-4 STAND RUBBER FOOT L4300UA 1EM422534
A9-5 SCREW P-TIGHT M3X8 BIND HEAD+
BLK
GBHP3080
A9-6 SHEET R L3219UK 1EM322093
A9-7 SHEET L L3219UK 1EM322098
A10 CONNECTOR CAP L2600UA 1EM423029
A18 A FRONT PLATE L2600UA 1EM221201
A18 B FRONT PLATE L3223UD 1EM221391
B3 STAND HOLDER L2500UA 1EM321428
B4 JACK HOLDER L3201UB 1EM120107
B5 CLOTH(10X30XT0.5) B5900UA 0EM404486
B9 INSULATION PLATE L3207UH 1EM421108
B12 TILT STAND HOLDER L3253UD 1EM321693
B14 SPEAKER HOLDER L2600UA 1EM423052
B18 CLOTH(10X190XT0.3) L0200UA 1EM420019
B23 CAUTION LABEL L3207UH ----------
B34 CLOTH 10X150XT1.0 1EM421092
B46 CLOTH(4X7X0.3T) TD250UA 0EM407578
CLN801 SPEAKER WIRE ASSEMBLY 2P WIRE
ASSEMBLY
WX1L3201-001
CLN802 SPEAKER WIRE ASSEMBLY 2P WIRE
ASSEMBLY
WX1L3201-001
L4 SCREW P-TIGHT M3*10
WASHERHEAD+
GCJP3100
L7 DOUBLE SEMS SCREW M4X12 + BLAK FPH34120
L9 SCREW P-TIGHT 3X10 BIND HEAD+ GBHP3100
L13 SCREW P-TIGHT 3X12 BIND HEAD+
BLK
GBHP3120
L17 SCREW S-TIGHT M3X8 BIND HEAD+ GBHS3080
L21 SCREW S-TIGHT M3X8 BIND HEAD+ GBJS3080
L22 SCREW P-TIGHT 3X14 WASHER
HEAD+
GCJP3140
L23 SCREW P-TIGHT M3X8 BIND HEAD+
BLK
GBHP3080
L25 ASSEMBLED SCREW M3X10 1EM420633A
L27 SCREW P-TIGHT M4X18 BIND HEAD+ GBHP4180
SP801 SPEAKER S0407F10 DSD0807XQ002
SP802 SPEAKER S0407F10 DSD0807XQ002
PACKING
S1 A CARTON L3219UK 1EM423033
S1 B CARTON L3223UD 1EM423214
S2 STYROFOAM TOP L2600UA 1EM121396
S3 STYROFOAM BOTTOM L2600UA 1EM121397
S4 SET BAG L0301UB 1EM320014A
S5 SERIAL NO. LABEL L9750UA ----------
ACCESSORIES
X1 BAG POLYETHYLENE 235X365XT0.03 0EM408420A
X2# A OWNERS MANUAL L3219UK 1EMN21591
X2# B OWNERS MANUAL L3223UD 1EMN21755
X3 A REMOTE CONTROL 170/ECNLC301/
NE903UD
NE903UD
X3 B REMOTE CONTROL 170/ECNLC301/
NE900UD
NE900UD
X5 DRY BATTERY R03/2S XB0M451T0006
Ref. No. Mark Description Part No.
