ELECTRICAL PARTS LIST
PRODUCT SAFETY NOTE: Products marked with a
# have special characteristics important to safety.
Before replacing any of these components, read
carefully the product safety notice in this service
manual. Don't degrade the safety of the product
through improper servicing.
NOTES:
1. Parts that are not assigned part numbers (---------)
are not available.
2. Tolerance of Capacitors and Resistors are noted
with the following symbols.
LCD MAIN CBA UNIT & LIQUID
CRYSTAL PANEL UNIT
MMA CBA
MAIN CBA
C.....±0.25% D.....±0.5% F.....±1%
G.....±2% J......±5% K.....±10%
M.....±20% N.....±30% Z.....+80/-20%
Ref. No. Description Part No.
LCD MAIN CBA UNIT & LIQUID CRYSTAL
PANEL UNIT
1FSA10052
Ref. No. Description Part No.
MMA CBA
Consists of the following:
1ESA12657
MAIN CBA
IR SENSOR CBA
FUNCTION CBA
----------
----------
----------
Ref. No. Description Part No.
MAIN CBA
Consists of the following:
----------
CAPACITORS
C11 ELECTROLYTIC CAP. 10µF/50V M CA1J100SP085
C12 CHIP CERAMIC CAP.(1608) B K 0.01µF/50V CHD1JK30B103
C13 CHIP CERAMIC CAP.(1608) B K 0.01µF/50V CHD1JK30B103
C14 CHIP CERAMIC CAP.(1608) CH J 100pF/50V CHD1JJ3CH101
C15 ELECTROLYTIC CAP 1µF/50V M CA1J1R0SP085
C16 CHIP CERAMIC CAP.(1608) CH J 100pF/50V CHD1JJ3CH101
C21 CHIP CERAMIC CAP.(1608) B K 0.01µF/50V CHD1JK30B103
C22 ELECTROLYTIC CAP. 100µF/10V M H7 CE1AMASSM101
C23 CHIP CERAMIC CAP.(1608) CH J 1000pF/50V CHD1JJ3CH102
C24 CHIP CERAMIC CAP.(1608) CH J 1000pF/50V CHD1JJ3CH102
C25 CHIP CERAMIC CAP.(1608) B K 0.01µF/50V CHD1JK30B103
C26 PCB JUMPER D0.6-P5.0 JW5.0T
C27 FILM CAP.(P) 0.018µF/50V J CA1J183MS029
C28 CHIP CERAMIC CAP.(1608) B K 0.047µF/50V CHD1JK30B473
C29 CHIP CERAMIC CAP. CH D 3pF/50V CHD1JD3CH3R0
C30 CHIP CERAMIC CAP.(1608) B K 0.01µF/50V CHD1JK30B103
C31 PCB JUMPER D0.6-P5.0 JW5.0T
C32 ELECTROLYTIC CAP. 100µF/10V M H7 CE1AMASSM101
C34 CHIP CERAMIC CAP.(1608) CH J 47pF/50V CHD1JJ3CH470
C35 ELECTROLYTIC CAP. 1µF/50V M H7 CE1JMASSM1R0
C36 CHIP CERAMIC CAP.(1608) CH J 47pF/50V CHD1JJ3CH470
C37 CHIP CERAMIC CAP. CH J 680pF/50V CHD1JJ3CH681
C39 ALUMINUM ELECTROLYTIC CAP 0.47µF/50V
H7
CE1JMASSMR47
C41 ELECTROLYTIC CAP. 4.7µF/50V M CA1J4R7SP085
C42 CHIP CERAMIC CAP.(1608) B K 0.01µF/50V CHD1JK30B103
C43 CHIP CERAMIC CAP.(1608) B K 0.01µF/50V CHD1JK30B103
C44 ELECTROLYTIC CAP. 100µF/10V M H7 CE1AMASSM101
C45 CHIP CERAMIC CAP.(1608) B K 0.01µF/50V CHD1JK30B103
C46 ELECTROLYTIC CAP. 47µF/16V M CA1C470SP085
C501 ELECTROLYTIC CAP. 22µF/50V M CA1J220SP085
C502 CHIP CERAMIC CAP.(1608) B K 0.01µF/50V CHD1JK30B103
C503 ELECTROLYTIC CAP. 220µF/16V M CA1C221SP085
C504 ELECTROLYTIC CAP. 100µF/10V M CA1A101SP085
C505 CHIP CERAMIC CAP.(1608) B K 0.01µF/50V CHD1JK30B103
C506 CHIP CERAMIC CAP.(1608) B K 0.01µF/50V CHD1JK30B103
C507 CHIP CERAMIC CAP.(1608) B K 0.01µF/50V CHD1JK30B103
C508 CHIP CERAMIC CAP.(1608) B K 0.01µF/50V CHD1JK30B103
C515 CHIP CERAMIC CAP.(1608) B K 0.01µF/50V CHD1JK30B103
C531 ELECTROLYTIC CAP. 330µF/50V M CA1J331SP084
C532 CHIP CERAMIC CAP.(1608) B K 0.22µF/25V CHD1EK30B224
C534 CHIP CERAMIC CAP. B K 1µF/16V CHD1CK30B105
C535 ELECTROLYTIC CAP. 470µF/16V M CA1C471SP085
C537 CHIP CERAMIC CAP.(1608) B K 0.01µF/50V CHD1JK30B103
C538 ELECTROLYTIC CAP. 10µF/50V M CA1J100SP085
C539 CHIP CERAMIC CAP.(1608) CH J 100pF/50V CHD1JJ3CH101
C601# METALIZED FILM CAP. 0.1µF/250V CT2E104MS037
C602# METALIZED FILM CAP. 0.1µF/250V CT2E104MS037
C605 CERAMIC CAP. F Z 0.01µF/500V CCD2JZP0F103
C606 CERAMIC CAP. F Z 0.01µF/500V CCD2JZP0F103
C608 CERAMIC CAP. B K 1000pF/2KV CCD3DKP0B102
C610# ELECTROLYTIC CAP. 100µF/200V M CE2DMZPDL101
C612 FILM CAP.(P) 0.01µF/50V J CMA1JJS00103
C613 FILM CAP.(P) 0.056µF/50V J CMA1JJS00563
C614 PCB JUMPER D0.6-P5.0 JW5.0T
C615 PCB JUMPER D0.6-P5.0 JW5.0T
C630# ELECTROLYTIC CAP. 2200µF/25V M CA1E222SP084
C631# ALUMINUM ELECTROLYTIC CAP 2200µF/35V
M
CE1GMZNTM222
C633# ELECTROLYTIC CAP. 220µF/16V M CA1C221SP085
C634# ELECTROLYTIC CAP. 1000µF/25V M CA1E102SP084
C635# ELECTROLYTIC CAP. 470µF/10V M CA1A471SP085
C636 CHIP CERAMIC CAP.(1608) B K 0.1µF/50V CHD1JK30B104
C637# ALUMINUM ELECTROLYTIC CAP 2200µF/35V
M
CE1GMZNTM222
C638 CHIP CERAMIC CAP.(1608) B K 0.1µF/50V CHD1JK30B104
C641# SAFETY CAP. 4700pF/250V KX CA2E472MR050
C642# ELECTROLYTIC CAP. 10µF/50V M CA1J100SP085
C644# ELECTROLYTIC CAP 100µF/50V M CA1J101SP085
C645# ELECTROLYTIC CAP. 10µF/50V M CA1J100SP085
C646 MYLAR CAP. 0.22µF/50V J CMA1JJS00224
C649 CHIP CERAMIC CAP.(1608) B K 0.01µF/50V CHD1JK30B103
C650 CHIP CERAMIC CAP.(1608) B K 0.01µF/50V CHD1JK30B103
C652# ELECTROLYTIC CAP. 1000µF/25V M CA1E102SP084
C654# ELECTROLYTIC CAP. 100µF/200V M CE2DMZPDL101
C657 ALUMINUM ELECTROLYTIC CAP 47µF/16V H7 CE1CMASSM470
C659 FILM CAP.(P) 0.022µF/50V J CMA1JJS00223
C660 FILM CAP.(P) 0.0068µF/50V J CMA1JJS00682
C671 ELECTROLYTIC CAP. 470µF/10V M CA1A471SP085
Ref. No. Description Part No.
To Next Page
