20060322 13-5 L3219EL
IR SENSOR CBA
FUNCTION CBA
INVERTER CBA
R842 CHIP RES. 1/10W J 22k Ω RRXAJR5Z0223
R843 CHIP RES. 1/10W J 22k Ω RRXAJR5Z0223
R844 CHIP RES. 1/10W J 2.2k Ω RRXAJR5Z0222
R851 CHIP RES. 1/10W J 100 Ω RRXAJR5Z0101
R852 CHIP RES. 1/10W J 100 Ω RRXAJR5Z0101
R853 CHIP RES. 1/10W J 3.3k Ω RRXAJR5Z0332
R855 CHIP RES. 1/10W J 180k Ω RRXAJR5Z0184
MISCELLANEOUS
AC601# AC CORD LP-11W&PT218P-K90A&S WAC0172LW020
B7 SHIELD BOX TOP L3201UB 1EM320159
B10 HEAT SINK PKH ASSEMBLY L3201UB 1EM420648
B22 POW HEAT SINK PKG ASSEMBLY L3201UB 1EM420650
BC401 PCB JUMPER D0.6-P5.0 JW5.0T
BC602 BEADS INDUCTOR FBR07HA121SB-00 LLBF00STU030
BC630 BEADS INDUCTOR FBR07HA121SB-00 LLBF00STU030
BC631 BEADS INDUCTOR FBR07HA121SB-00 LLBF00STU030
BC632 PCB JUMPER D0.6-P5.0 JW5.0T
BC634 PCB JUMPER D0.6-P5.0 JW5.0T
BC635 PCB JUMPER D0.6-P5.0 JW5.0T
BC636 BEADS INDUCTOR FBR07HA121SB-00 LLBF00STU030
CF31 CERAMIC FILTER SFSRA4M50CF00-B0 FBB455PMR004
F601# FUSE STC4A125V U/CT PAGE20CW3402
FH601 FUSE HOLDER MSF-015 LF (B110) XH01Z00LY002
FH602 FUSE HOLDER MSF-015 LF (B110) XH01Z00LY002
GP641# GAP. FNR-G3.10D FAZ000LD6005
JK701 Y/C JACK 1P(SW) DMDC1-01-021 JYEL040RP001
JK703 JACK RCA PCB L RCA-112(2)-04(YL) JXRL010YUQ10
JK704 JACK RCA PCB L RCA-112(2)-04(WH) JXRL010YUQ11
JK705 JACK SW RCA PCB L RCA-112-03(RD) JYRL010YUQ02
JK706 RCA JACK(GREEN) MTJ-032-08B-41 FE( JXRL010LY126
JK707 RCA JACK(BLUE) MTJ-032-08B-44 FE JXRL010LY130
JK708 JACK RCA PCB L RCA 112(2) 04(RD) JXRL010YUQ16
JK709 JACK RCA PCB L RCA-112(2)-04(WH) JXRL010YUQ11
JK710 JACK SW RCA PCB L RCA-112-03(RD) JYRL010YUQ02
JK801 JACK SW HPEP SML PCB L PJ-323-7 JYSL020YUQ02
JS524 PCB JUMPER D0.6-P5.0 JW5.0T
JS631 PCB JUMPER D0.6-P5.0 JW5.0T
JS634 PCB JUMPER D0.6-P5.0 JW5.0T
JS636 PCB JUMPER D0.6-P5.0 JW5.0T
JS805 PCB JUMPER D0.6-P5.0 JW5.0T
JS806 PCB JUMPER D0.6-P5.0 JW5.0T
JS813 CHIP RES.(1608) 1/10W 0 Ω RRXAZR5Z0000
L16 SCREW B-TIGHT D3X8 BIND HEAD+ GBJB3080
SA601# SURGE ABSORBER 470V+-10PER NVQZ10D471KB
SF11 SAW FILTER SAFHM45M7VAJZ01B03 FBB456PMR012
T601# SWITCHING TRANS 5723 LTT00CPKT182
TP401 PCB JUMPER D0.6-P20.0 JW20.0T
TU1 TUNER UNIT TEFH9-002A UTUNNTUAL045
Ref. No. Description Part No.
IR SENSOR CBA
Consists of the following:
----------
CAPACITOR
C102 ELECTROLYTIC CAP. 47µF/10V M H7 CE1AMASSM470
RESISTORS
R123 CHIP RES. 1/10W J 68 Ω RRXAJR5Z0680
R124 CHIP RES. 1/10W J 68 Ω RRXAJR5Z0680
MISCELLANEOUS
CLN105 WIRE ASSEMBLY 5PIN 560MM AWG26 WX1L3219-002
RCV102 REMOCON RECEIVE UNIT PIC-37042SR USESJRSKK034
Ref. No. Description Part No.
Ref. No. Description Part No.
FUNCTION CBA
Consists of the following:
----------
CAPACITOR
C103 CERAMIC CAP.(AX) B 0.01µF/50V CCK1JKT0B103
RESISTORS
R101 CHIP RES. 1/10W J 10k Ω RRXAJR5Z0103
R102 CARBON RES. 1/4W J 47 Ω RCX4JATZ0470
R103 CARBON RES. 1/4W J 1.5k Ω RCX4JATZ0152
R104 CHIP RES. 1/10W J 1.5k Ω RRXAJR5Z0152
R105 CHIP RES. 1/10W J 2.2k Ω RRXAJR5Z0222
R106 CHIP RES. 1/10W J 2.7k Ω RRXAJR5Z0272
R107 CARBON RES. 1/4W J 4.7k Ω RCX4JATZ0472
R108 CHIP RES. 1/10W J 6.8k Ω RRXAJR5Z0682
R109 CARBON RES. 1/4W J 10k Ω RCX4JATZ0103
R110 CARBON RES. 1/4W J 47 Ω RCX4JATZ0470
SWITCHES
SW101 TACT SWITCH SKQSAB SST0101AL038
SW102 TACT SWITCH SKQSAB SST0101AL038
SW103 TACT SWITCH SKQSAB SST0101AL038
SW104 TACT SWITCH SKQSAB SST0101AL038
SW105 TACT SWITCH SKQSAB SST0101AL038
SW107 TACT SWITCH SKQSAB SST0101AL038
SW111 TACT SWITCH SKQSAB SST0101AL038
MISCELLANEOUS
CLN104 8P WIRE ASSEMBLY WX1L3101-003 WX1L3101-003
JS121 CHIP RES.(1608) 1/10W 0 Ω RRXAZR5Z0000
JS122 CHIP RES.(1608) 1/10W 0 Ω RRXAZR5Z0000
Ref. No. Description Part No.
INVERTER CBA
Consists of the following:
1ESA12658
CAPACITORS
C401 ELECTROLYTIC CAP. 47µF/35V M CA1G470SP085
C402 CHIP CERAMIC CAP.(1608) B K 0.1µF/50V CHD1JK30B104
C403 ELECTROLYTIC CAP. 100µF/16V M CA1C101SP085
C404 CHIP CERAMIC CAP.(1608) B K 0.01µF/50V CHD1JK30B103
C405 CHIP CERAMIC CAP.(1608) B K 0.047µF/50V CHD1JK30B473
C406 CHIP CERAMIC CAP. CH J 220pF/50V CHD1JJ3CH221
C407 CHIP CERAMIC CAP.(1608) B K 6800pF/50V CHD1JK30B682
C408 CHIP CERAMIC CAP.(1608) B K 4700pF/50V CHD1JK30B472
C409 CHIP CERAMIC CAP.(1608) B K 6800pF/50V CHD1JK30B682
C410 CHIP CERAMIC CAP.(1608) B K 4700pF/50V CHD1JK30B472
C412 CHIP CERAMIC CAP.(1608) B K 0.1µF/50V CHD1JK30B104
C413 ELECTROLYTIC CAP. 0.22µF/50V M CA1JR22SP085
C414 ELECTROLYTIC CAP. 2.2µF/50V M CA1J2R2SP085
C415 ELECTROLYTIC CAP. 2.2µF/50V M CA1J2R2SP085
C416 CHIP CERAMIC CAP.(1608) B K 0.1µF/50V CHD1JK30B104
C420 ELECTROLYTIC CAP. 47µF/35V M CA1G470SP096
C422 CHIP CERAMIC CAP.(1608) B K 0.1µF/50V CHD1JK30B104
C423 ELECTROLYTIC CAP. 47µF/35V M CA1G470SP096
C425 CHIP CERAMIC CAP.(1608) B K 0.1µF/50V CHD1JK30B104
C426 ELECTROLYTIC CAP. 47µF/35V M CA1G470SP096
C428 CHIP CERAMIC CAP.(1608) B K 0.1µF/50V CHD1JK30B104
C429 CHIP CERAMIC CAP. B K 4.7µF/25V CHF1EK30B475
C430 CHIP CERAMIC CAP. B K 4.7µF/25V CHF1EK30B475
C431 CHIP CERAMIC CAP. B K 4.7µF/25V CHF1EK30B475
C432 CHIP CERAMIC CAP. B K 4.7µF/25V CHF1EK30B475
C433 CHIP CERAMIC CAP. B K 4.7µF/25V CHF1EK30B475
C434 CHIP CERAMIC CAP. B K 4.7µF/25V CHF1EK30B475
To Next Page
