CAUTION:
Do not wipe plastic components, e.g. instrument panel, headlight, with organic solvents such as
gasoline…etc to avoid damaging these components.
The panel figure for speedometer may vary from model to model, but the location usually are the
same.
7.
USE OF EACH COMPONENT
(The following is SYM 4 stroke air-cooling 125 c.c. scooter’s basic operation, and they
could vary from different individual models. Please consult the end of this manual.)
§GAUGES §
 Speedometer：
Indicates driving speed.
 Odometer：
Indicates total accumulated distance
traveled.
 High Beam Indicator：
This indicator comes on with high beam
headlight is turned on.
 Turn (left/right) Signal Indicator：
The left or right Indicator will be flashing
according to the operated directions of turn
signal light switch when it is turned on.
 Fuel Meter:
The pointer in this meter shows how much
fuel remains in the tank.
The pointer stays in “E” position when key
switch is turned to “OFF”.
 Fault indicator light
If there is something wrong with the ECS, the warning light will light all the time.
Speedometer
Odometer
Turn Left Signal Indicator
Turn Right Signal Indicator
High Beam Indicator
Fuel meter
ECS Fault Light
