11. CRANKCASE/CRANKSHAFT SYM
11-2
OPERATIONAL PRECAUTIONS
General Information
This Section contains descriptions concerning disassembly of the crankcase so that the
crankshaft can be serviced.
Complete following operations before disassembling crankcase.
Engine Chapter 5
Cylinder head Chapter 6
Cylinder and piston Chapter 7
V-belt Drive pulley Chapter 8
AC generator/ Starting Clutch Chapter 10
If the crankshaft bearing or timing sprocket need be replaced, then the crankshaft set have to
replaced.
Specification Unit: mm
Item Standard Limit
Left, right clearance of the big end of the connecting rod
0.100~0.350 0.550
Radial clearance of the big end of the connecting rod
0.000~0.008 0.050
Run-out
─
Below 0.030
Torque value
Bolts for crankcase 0.8~1.2 kgf-m
Bolts for cylinder/cylinder head 0.8~1.2 kgf-m
Engine oil draining plug 3.5~4.5 kgf-m
Bolts for cam chain tensioner 0.8~1.2 kgf-m
Special Service Tools
Crankcase remover/set
Crankshaft installation puller
Inner type bearing puller
Outer type bearing puller
Bearing pressing tools
Oil seal pressing tools
TROUBLE DIAGNOSIS
Engine noise
• Loose crankshaft bearing
• Loose crankshaft pin bearing
• Wear piston pin or piston pin hole
