1. GENERAL INFORMATION/TROUBLE DIAGNOSIS SYM
1-10
TORQUE VALUES (ENGINE)
ITEM Q'TY
THREAD DIA
(mm)
TORQUE
VALUE(Kg-m)
REMARKS
Cylinder head bolts 4 6 0.8~1.2
Cylinder head nuts 4 8 1.8~2.2 Apply oil to thread
Cylinder/cylinder head two-ends bolts 4 7 0.7~1.1 Tighten to crankcase
Cam holder nut 4 7 1.0~1.4
Right crank case cover bolts 10 6 0.8~1.2
Pulse generator bolts 2 5 0.35~0.5
Valve adjustment fixing nuts 2 5 0.7~1.1 Apply oil to thread
Spark plug 1 10 1.0~1.4
Engine oil strainer cap 1 30 1.0~2.0
Gear oil draining plug 1 8 1.0~1.5
Gear oil filling bolt 1 8 1.0~1.5
Oil pump bolts 3 6 0.8~1.2
Oil pump drive sprocket nuts 1 6 0.8~1.2
Left crankcase cover bolts 10 6 0.8~1.2
Cylinder head cover bolts 4 6 0.8~1.2
Camshaft chain tensioner pivot 1 6 0.8~1.2 Hex socket bolt
Camshaft chain adjuster bolts 2 6 1.0~1.4
Cooling fan bolts 4 6 0.8~1.2
Shroud A/B 2 6 0.8~1.2
RR. brake fixing nut 1 8 1.5~2.0
Flywheel nut 1 10 3.5~4.5
Transmission(Gear box) bolts 7 8 2.6~3.0
RR. brake arm bolt 1 6 0.7~1.1
Drive face nut 1 12 5.0~6.0
Drive pulley nut 1 10 3.5~4.5
A.C. generator flange bolt 2 6 0.8~1.2
Air/C connect bracket bolts 2 6 0.8~1.2
Start motor bolts 2 6 0.8~1.2
Brake arm bolt 1 6 0.7~1.1
Kick starter arm bolt 1 6 0.8~1.2
Carburetor nut 2 6 0.8~1.2
A.I. fixing hex cap nut 2 6 0.8~1.2
Crankcase bolts 1 6 0.8~1.2
Exhaust pipe bolts 2 8 3.0~3.6
Exhaust pipe connecting nuts 2 6 1.0~1.4
