Page #18 background image
SYM 1. GENERAL INFORMATION/TROUBLE DIAGNOSIS
1-11
TORQUE VALUES (FRAME)
ITEM Q'TY
THREAD DIA
(mm)
TORQUE
VALUE(Kg-m)
REMARKS
Mounting bolt for steering
handlebar
1 10 4.0~5.0
Mounting nut for steering rod 1 25.4 1.0~2.0
Cone seat for steering rod 1 25.4 0.2~0.3
Front wheel shaft nut 1 12 5.0~7.0
Rear wheel shaft nut 1 16 11.0~13.0
Wheel hub/rim mounting nuts 8 8 2.8~3.2
Speedometer cable locking screw 1 5 0.15~0.3
Front shock absorber mounting
bolts
4 8 2.4~3.0
Rear shock absorber upper
connection bolt
1 10 3.5~4.5
Rear shock absorber upper
connection bolt
1 8 2.4~3.0
Brake lever bolts 2 6 0.8~1.2
Front brake hose bolts 2 10 3.3~3.7
Front brake air-bleeding valve 1 6 0.8~1.0
Front brake disc mounting bolts 4 10 4.0~4.5
Front brake clipper mounting bolts 2 10 3.1~3.5
Drum brake arm bolts (front/rear) 2 6 0.8~1.2
Engine suspension bracket bolts 2 10 4.5~5.5 On frame side
Engine connection bolt 1 10 4.5~5.5 On engine side
Main standard nut 1 10 3.5~4.5
Foot-starting lever bolt 1 6 1.6~1.8
Air cleaner bolts 2 6 1.0~1.4
The torque values listed in above table are for more important tighten torque values. Please see
standard values for not listed in the table.
Standard Torque Values for Reference
TYPE TIGHTEN TORQUE TYPE TIGHTEN TORQUE
5mm boltnut
0.45~0.60kgf-m
3mm screw
0.05~0.08kgf-m
6mm boltnut
0.80~1.20kgf-m 4mm screw 0.10~0.15kgf-m
8mm boltnut
1.80~2.50kgf-m 5mm screw 0.35~0.50kgf-m
10mm boltnut
3.00~4.00kgf-m
6mm screwSH nut
0.70~1.10kgf-m
12mm boltnut
5.00~6.00kgf-m
6mm boltnut
1.00~1.40kgf-m
8mm boltnut
2.40~3.00kgf-m
10mm boltnut
3.50~4.50kgf-m
