Sym Mio 50 - Front Cover Removal and Installation

12. Body Cover
12-3
Front Cover
Removal
Remove the mounting screws (2 screws) of front
cover from the front inner cover side.
Remove the front mounting screw (1 screw) of the
front cover.
Push the front cover upward and then pull it
forward so that the lower mounting groove of front
cover can be separated from the front under
spoiler.
Disconnect the headlight and position light wire
coupler.
Remove the front cover.
Installation
Install according to the reverse procedure of
removal.
1 screw
Light coupler
2 Screws
