SYMEO Local Positioning Radar System
LPR®-1D24
LPR®-1D24 Station – Overview and Mounting
Specification of the Connectors
Copyright © SYMEO GmbH 2015
LPR-1D24_Users_Manual_FCC-IC-Edition_EN.docx Page 16 of 34
5.4.1 Plugs
Recommended connector:
Connector: SCPU-10-G-02.00-MBS-AM from Samtec
USB mini-B-plug
Pin assignment according to USB-Standard
If the USB-port at the device is not used, it must be closed with the end
cap to prevent leakage.
5.5 USB – A Devices
The LPR
®
-1D24 unit has a USB-Flash Drive Connector, on which the data can be logged for
service purposes (Figure 4 – Connection B8).
