7 Web User Interface for LPR
®
-1D24
This chapter describes the LPR
®
-1D24 Web User Interface.
Connection via the Ethernet is required!
For the Ethernet-connection the connector cable M12 – RJ45 is required
for configuration of the LPR
®
-1D24 units with M12 plug and RJ 45
connector. This connector cable can be ordered by Symeo (see 5.3.3).
7.1 Requirements
In order for a unit to be successfully commissioned, the LPR
®
-1D24 components must have
been installed correctly:
 The unit has been connected to the power supply.
 Data link has been established over TCP/IP.
Once these prerequisites have been fulfilled, you can connect the unit to the network and
commission the LPR
®
-1D24 system. How to do this is explained in the following chapters.
7.1.1 Connection to LPR
®
-1D24 Unit
At delivery the IP-address of the LPR
®
-1D24 unit is set to 192.168.1.99, if
no other IP-Address is labeled outside the LPR
®
-1D24 unit.
You can change the IP-Address of the LPR
®
-1D24 unit via the web
interface of the LPR
®
-Unit.
To get a connection between your PC and the LPR
®
-1D24 unit it is maybe
necessary to change the network parameters of your computer. The PC
and the LPR
®
-1D24 unit must be located in the same network. That means
in this example that the first three numeric pads of both IP-addresses must
be the same.
 Disconnect your PC from the network.
 Connect the LPR
®
-1D24 unit and the computer with a network cable.
 Open the network settings of your computer (see picture below).
